可用覆蓋波形(-6dB標準) 水平x垂直 | 60x40, 60x60, 90x40, 90x60, 90x90, 120x60 d° |
環境參數 | Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55 |
輸入連接 | Phoenix/Euroblock style screw terminals; PI and FG versions include dual-gland-nut input-panel cover |
內置無源分頻點 | 1450Hz |
頻率響應(-3分貝) | 58 - 16000Hz |
頻率響應(-10分貝) | 49 - 19000Hz |
建議高通頻率 | 65Hz |
靈敏度(1瓦/1米) | 98dB |
最大. 聲壓級/1米 (計算) | 131dB |
系統功率處理(連續/音樂//峰值) | 500, 1000, 2000 Watts |
低頻換能器 | SMX2121 12-inch (305 mm) driver |
高頻換能器 | ND2B 2-inch (51 mm) diaphragm compression driver |
額定阻抗 | 8 Ω |
最小負荷阻抗 | 6 Ω |
箱體材料 | 13-ply weather-resistant birch |
柵格 | Standard versions: 16-ga Galvanneal, Powdercoat, with screen behind PI and FG versions: 18-ga Stainless, Powdercoat, with hydrophobic cloth behind |
吊掛 | (22) M10 Threaded Points (one EBK-M10-EVI kit of four forged eyebolts included) |
高度 | 768.6mm (30.26") |
寬度 | 406.3mm (16") |
深度 | 413.3mm (16.27") |
凈重 | 28.6kg (63.05lbs) |
